Dursteel Mn
Manganese Steel
Dursteel Mn is a work-hardening, non-magnetic manganese steel.
Its non-hardened (austenitic) structure provides very high toughness.
The work-hardened (martensitic) structure, reaching up to 540 HB, provides very high abrasion resistance.
DURSTEEL Mn wear-resistant steel, featuring a work-hardening surface layer (1 to 3 mm thick) and a ductile core, is ideal for many applications combining impact and abrasion.
Technical & general information for manganese abrasion-resistant steel
Hardness of manganese wear-resistant steel:
Available stock sizes (in mm):
Plates (1000×1000 or 1500×3000)
Thickness: 2, 3, 4, 6, 8, 10, 12, 15, 20, 25
Rounds (Length 6000)
Ø 12, 20, 25, 30, 35
Rectangular section (Length 6000)
Thickness: 6: Width 35, 40
Thickness: 8: Width 40
Thickness: 10: Width 40, 50, 60
Thickness: 12: Width 30, 40
Thickness: 15: Width 40
Thickness: 20: Width 120
Channel section (Length 6000)
Thickness: 10: Width 30, 40, 50
Thickness: 12: Width 60
Thickness: 20: Width 70
Mechanical properties for Dursteel Mn martensitic steel:
Yield strength RP 0.2: 325 MPa
Tensile strength RM: 920 MPa
A%: 50
Impact energy: 27 J at −20°C
*Typical value for a thickness of 20 mm
Forming of Dursteel Mn:
Dursteel Mn is difficult to drill. It requires 12% cobalt tools or carbide inserts.
Feed must be sufficient to remove the work-hardened zone during each pass.
Sharpening should be checked regularly.
NB: It is possible to obtain smooth holes with a diameter equal to the plate thickness (minimum diameter 10 mm) by plasma cutting. Please consult us on this subject.
Weldability of Dursteel Mn wear-resistant steel:
Dursteel Mn can be welded easily on construction steel bases.
Filler metals:
Electrodes type Safinox R312 or equivalent
Solid wire type Nertalic 51 or equivalent
Hardfacing of Dursteel Mn abrasion-resistant steel:
Dursteel Mn abrasion-resistant steel can be repaired or harfaced using materials of similar chemical composition.
Filler metals:
Electrodes type Safuni Manga or equivalent
Main applications of Dursteel Mn
- Anti-tamper grates
- Screen grates
- Scalper bars
- Guide rails
- Crusher knives
- Sliding plates for chain conveyors
- Crusher hammers
- Shot-blasting machine liners
- Impact plates
- Striking tools
- Safe and vault linings
- Vehicle armor
- …
Why choose Dursteel Mn ?
Dursteel Mn offers exceptional resistance in environments where abrasion and impact occur simultaneously.
Under the effect of impacts, its surface work-hardens naturally over 1 to 3 mm and can reach up to 540 HB, while its core remains tough (≈200 HB).
This transformation, from austenite to a very hard martensitic structure, ensures a service life far superior to conventional steels in highly stressed areas.
Conversely, if mechanical stresses are too low to trigger this work-hardening, Dursteel Mn is not the ideal solution (consult us for a suitable alternative).
